Name: Structures

Display Field: STRUC_ID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description:

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: true

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.1709569000311643E7
YMin: 6878758.999727622
XMax: 1.1846111073479772E7
YMax: 7025067.000437275
Spatial Reference: 102746  (2283)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Symbology
Field 2: N/A
Field 3: N/A
Field Delimiter: ;
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 10
  Label: 10 - Manholes or junction boxes maintained by County
  Description: N/A
  Symbol:

• Value: 12
  Label: 12 - Manholes or junction boxes located in SWM facilities
  Description: N/A
  Symbol:

• Value: 213
  Label: 213 - End Sections, End Walls, and Headwalls maintained by County
  Description: N/A
  Symbol:

• Value: 413 - End Sections, End Walls, and Headwalls located in SWM facilities
  Label: 413 - End Sections, End Walls, and Headwalls located in SWM facilities
  Description: N/A
  Symbol:

• Value: 413
  Label: 413 - End Sections, End Walls, and Headwalls located in SWM facilities
  Description: N/A
  Symbol:

• Value: 6 - Drop inlets or yard inlets maintained by County
  Label: 6 - Drop inlets or yard inlets maintained by County
  Description: N/A
  Symbol:

• Value: 6
  Label: 6 - Drop inlets or yard inlets maintained by County
  Description: N/A
  Symbol:

• Value: 8 - Drop inlets or yard inlets located in SWM facilities
  Label: 8 - Drop inlets or yard inlets located in SWM facilities
  Description: N/A
  Symbol:

• Value: 8
  Label: 8 - Drop inlets or yard inlets located in SWM facilities
  Description: N/A
  Symbol:

• Value: 82 - Tee connections maintained by County
  Label: 82 - Tee connections maintained by County
  Description: N/A
  Symbol:

• Value: 82
  Label: 82 - Tee connections maintained by County
  Description: N/A
  Symbol:

• Value: 84 - Tee connections located in SWM easement
  Label: 84 - Tee connections located in SWM easement
  Description: N/A
  Symbol:

• Value: 84
  Label: 84 - Tee connections located in SWM easement
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• STRUC_ID ( type: esriFieldTypeInteger, alias: Structure ID )
• OUTFALL ( type: esriFieldTypeInteger, alias: Outfall )
• Symbology ( type: esriFieldTypeInteger, alias: Symbology , Coded Values: [0: 0 - Pipe end (No maintenance associated with this symbol)] , [5: 5 - Drop inlets or yard inlets maintained by others] , [6: 6 - Drop inlets or yard inlets maintained by County] , ...10 more... )
• TopElevation ( type: esriFieldTypeDouble, alias: Top Elevation )
• BottomElevation ( type: esriFieldTypeDouble, alias: Bottom Elevation )
• DEPTH ( type: esriFieldTypeDouble, alias: Depth )
• FieldSurvey ( type: esriFieldTypeString, alias: Field Survey, length: 1 , Coded Values: [N: N - No] , [Y: Y - Yes] )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• DrainageArea ( type: esriFieldTypeDouble, alias: Drainage Area )
• LandUse ( type: esriFieldTypeString, alias: Land Use, length: 8 , Coded Values: [C: C - Commercial] , [IND: IND - Industrial] , [U: U - Utility] , ...22 more... )
• MS4RegOutfall ( type: esriFieldTypeString, alias: MS4 Regulated Outfall, length: 5 , Coded Values: [N: N - No] , [Y: Y - Yes] )
• CreatedUser ( type: esriFieldTypeString, alias: CreatedUser, length: 255 )
• CreatedDate ( type: esriFieldTypeDate, alias: CreatedDate, length: 8 )
• LastEditedUser ( type: esriFieldTypeString, alias: LastEditedUser, length: 255 )
• LastEditedDate ( type: esriFieldTypeDate, alias: LastEditedDate, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )

Relationships:

• SegmentInspectionTable (0) -- Related To: Structure Inspection Table (3)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates
