Name: Sewer Lines

Display Field: ASSET_ID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The data layer contains line features of the sanitary sewage utility system within Prince William County, Virginia. This layer contains type and status information related to the physical feature being represented as well as information related to the currency of the digital representation of the sanitary sewer utility asset. This data came directly from the PWC Service Authority who maintains the data continuously but provides data deliveries on a quarterly basis. Upon delivery the data was translated from three featureclasses in the PWC Service Authority data schema to a consolidated featureclass with subtypes in the PWC GIS data schema. Last updated on: 01/16/2025

Copyright Text: Prince William County Service Authority, Prince William County Department of Information Technology (DoIT), Geographic Information Systems (GIS) Division

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.171854037634106E7
YMin: 6878687.71029672
XMax: 1.1845639773388475E7
YMax: 6998868.227809221
Spatial Reference: 102746  (2283)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SUBTYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 1
Default Label: <all other values>
UniqueValueInfos:
• Value: 0
  Label: Gravity Main Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [252, 246, 207, 255]
  Width: 1
• Value: 1
  Label: Force Main Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [245, 179, 252, 255]
  Width: 1
• Value: 2
  Label: Lateral Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [179, 221, 252, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: SUBTYPE

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SUBTYPE ( type: esriFieldTypeInteger, alias: Subtype )
• ASSET_ID ( type: esriFieldTypeString, alias: ASSET_ID, length: 15 )
• OWNERSHIP ( type: esriFieldTypeString, alias: OWNERSHIP, length: 50 )
• STATUS ( type: esriFieldTypeString, alias: STATUS, length: 50 )
• ASSET_SIZE ( type: esriFieldTypeDouble, alias: ASSET_SIZE )
• MATERIAL ( type: esriFieldTypeString, alias: MATERIAL, length: 50 )
• EXTERIOR_PROTECTION ( type: esriFieldTypeString, alias: EXTERIOR_PROTECTION, length: 50 )
• TRACE_MECHANISM ( type: esriFieldTypeString, alias: TRACE_MECHANISM, length: 50 )
• IS_BONDED ( type: esriFieldTypeSmallInteger, alias: IS_BONDED )
• LINER_MATERIAL ( type: esriFieldTypeString, alias: LINER_MATERIAL, length: 50 )
• ASSET_FUNCTION ( type: esriFieldTypeString, alias: ASSET_FUNCTION, length: 25 )
• IS_TRUNK ( type: esriFieldTypeSmallInteger, alias: IS_TRUNK )
• PIPE_ENVIRONS ( type: esriFieldTypeString, alias: PIPE_ENVIRONS, length: 50 )
• ASSET_UPSTREAM ( type: esriFieldTypeString, alias: ASSET_UPSTREAM, length: 25 )
• ASSET_DOWNSTREAM ( type: esriFieldTypeString, alias: ASSET_DOWNSTREAM, length: 25 )
• INVERT_UPSTREAM ( type: esriFieldTypeDouble, alias: INVERT_UPSTREAM )
• INVERT_DOWNSTREAM ( type: esriFieldTypeDouble, alias: INVERT_DOWNSTREAM )
• CONSTRUCTION_DATE ( type: esriFieldTypeDate, alias: CONSTRUCTION_DATE, length: 8 )
• LINER_DATE ( type: esriFieldTypeDate, alias: LINER_DATE, length: 8 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: CREATED_DATE, length: 8 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: LAST_EDITED_DATE, length: 8 )
• COMMENTS_INTERNAL ( type: esriFieldTypeString, alias: COMMENTS_INTERNAL, length: 1000 )
• COMMENTS_EXTERNAL ( type: esriFieldTypeString, alias: COMMENTS_EXTERNAL, length: 1000 )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 25 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Types:

ID: 0
Name: Gravity Main Line
Domains:
• ASSET_SIZE:
  Coded Values: [0: Unknown] , [0.625: 5/8"] , [0.75: 3/4"] , ...36 more...
• MATERIAL:
  Coded Values: [DIP: Ductile Iron] , [CIP: Cast Iron] , [GIP: Galvanized Iron] , ...35 more...
• IS_BONDED:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]
• IS_TRUNK:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]

---

ID: 1
Name: Force Main Line
Domains:
• ASSET_SIZE:
  Coded Values: [0: Unknown] , [0.625: 5/8"] , [0.75: 3/4"] , ...36 more...
• MATERIAL:
  Coded Values: [DIP: Ductile Iron] , [CIP: Cast Iron] , [GIP: Galvanized Iron] , ...35 more...
• IS_BONDED:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]
• IS_TRUNK:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]

---

ID: 2
Name: Lateral Line
Domains:
• ASSET_SIZE:
  Coded Values: [0: Unknown] , [0.625: 5/8"] , [0.75: 3/4"] , ...36 more...
• MATERIAL:
  Coded Values: [DIP: Ductile Iron] , [CIP: Cast Iron] , [GIP: Galvanized Iron] , ...35 more...
• IS_BONDED:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]
• IS_TRUNK:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]

---

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
