Name: Water Points

Display Field: FACILITY_NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: The data layer contains point features of the water utility system within Prince William County, Virginia. This layer contains type and status information related to the physical feature being represented as well as information related to the currency of the digital representation of the water utility asset. This data came directly from the PWC Service Authority who maintains the data continuously but provides data deliveries on a quarterly basis.Upon delivery the data was translated from seven featureclasses in the PWC Service Authority data schema to a consolidated featureclass with subtypes in the PWC GIS data schemaLast updated on: 01/16/2025

Copyright Text: Prince William County Service Authority, Prince William County Department of Information Technology (DoIT), Geographic Information Systems (GIS) Division

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.1716725385220394E7
YMin: 6878165.445593223
XMax: 1.1845686702428475E7
YMax: 7022723.608576059
Spatial Reference: 102746  (2283)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SUBTYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSMSCircle
Color: [130, 130, 130, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Default Label: <all other values>
UniqueValueInfos:
• Value: 0
  Label: Fitting
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [252, 224, 207, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: 1
  Label: Meter Crock
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [188, 179, 252, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: 2
  Label: Meter Station
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [179, 252, 180, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: 3
  Label: Pump Station
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [179, 232, 252, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: 4
  Label: Tank
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [252, 182, 230, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: 5
  Label: Valve
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [212, 252, 228, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: 6
  Label: Well
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [252, 248, 182, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: 7
  Label: Flush Station
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [227, 215, 252, 255]
  Size: 4.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: SUBTYPE

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SUBTYPE ( type: esriFieldTypeInteger, alias: SUBTYPE )
• ASSET_ID ( type: esriFieldTypeString, alias: ASSET_ID, length: 15 )
• OWNERSHIP ( type: esriFieldTypeString, alias: OWNERSHIP, length: 50 )
• STATUS ( type: esriFieldTypeString, alias: STATUS, length: 50 )
• ASSET_TYPE ( type: esriFieldTypeString, alias: ASSET_TYPE, length: 50 )
• ASSET_FUNCTION ( type: esriFieldTypeString, alias: ASSET_FUNCTION, length: 50 )
• ASSET_SIZE ( type: esriFieldTypeDouble, alias: ASSET_SIZE )
• SECONDARY_SIZE ( type: esriFieldTypeDouble, alias: SECONDARY_SIZE )
• CAPACITY ( type: esriFieldTypeDouble, alias: CAPACITY )
• FACILITY_ID ( type: esriFieldTypeString, alias: FACILITY_ID, length: 10 )
• FACILITY_NAME ( type: esriFieldTypeString, alias: FACILITY_NAME, length: 50 )
• POSITION ( type: esriFieldTypeString, alias: POSITION, length: 25 )
• ENCLOSURE ( type: esriFieldTypeString, alias: ENCLOSURE, length: 25 )
• MANUFACTURER ( type: esriFieldTypeString, alias: MANUFACTURER, length: 50 )
• YR_MANUFACTURED ( type: esriFieldTypeSmallInteger, alias: YR_MANUFACTURED )
• IS_UNAVAILABLE ( type: esriFieldTypeSmallInteger, alias: IS_UNAVAILABLE )
• IS_LEFT_HANDED ( type: esriFieldTypeSmallInteger, alias: IS_LEFT_HANDED )
• RESTRAINT_TYPE ( type: esriFieldTypeString, alias: RESTRAINT_TYPE, length: 50 )
• GROUND_ELEVATION ( type: esriFieldTypeDouble, alias: GROUND_ELEVATION )
• IS_LOCKED ( type: esriFieldTypeSmallInteger, alias: IS_LOCKED )
• CONSTRUCTION_DATE ( type: esriFieldTypeDate, alias: CONSTRUCTION_DATE, length: 8 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: CREATED_DATE, length: 8 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: LAST_EDITED_DATE, length: 8 )
• COMMENTS_INTERNAL ( type: esriFieldTypeString, alias: COMMENTS_INTERNAL, length: 1000 )
• COMMENTS_EXTERNAL ( type: esriFieldTypeString, alias: COMMENTS_EXTERNAL, length: 1000 )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 25 )
• HAS_PRV ( type: esriFieldTypeSmallInteger, alias: Has Pressure Release Valve )
• DISCHARGE_POINT ( type: esriFieldTypeString, alias: DISCHARGE_POINT, length: 20 )
• FREEZE_PROOF ( type: esriFieldTypeSmallInteger, alias: FREEZE_PROOF )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Types:

ID: 0
Name: Fitting
Domains:
• ASSET_SIZE:
  Coded Values: [0: Unknown] , [0.625: 5/8"] , [0.75: 3/4"] , ...36 more...
• SECONDARY_SIZE:
  Coded Values: [0: Unknown] , [0.625: 5/8"] , [0.75: 3/4"] , ...36 more...

---

ID: 1
Name: Meter Crock
Domains:

---

ID: 2
Name: Meter Station
Domains:

---

ID: 3
Name: Pump Station
Domains:

---

ID: 4
Name: Tank
Domains:

---

ID: 5
Name: Valve
Domains:
• ASSET_SIZE:
  Coded Values: [0: Unknown] , [0.625: 5/8"] , [0.75: 3/4"] , ...36 more...
• IS_UNAVAILABLE:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]
• IS_LEFT_HANDED:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]
• IS_LOCKED:
  Coded Values: [1: Yes] , [0: No] , [-1: Unknown]

---

ID: 6
Name: Well
Domains:

---

ID: 7
Name: Flush Station
Domains:

---

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
